Description

AUXILIARY INFRARED CAMERA

Ideal for both night and day driving, this auxiliary infrared camera from ARB provides enhanced visibility in low light conditions.

Complete with infrared sensors, this camera provides for up to 10 metres of vision in dark conditions when vision is at its lowest.


ARB REVERSING CAMERA AND MONITOR RANGE
Offering exceptional reversing visibility in any circumstance, ARB’s range of reversing cameras and monitoring systems increase vehicle safety and help take the stress out of reversing.

ARB’s reversing camera and monitoring systems, trailer camera kits and auxiliary cameras extend the driver’s vision to the rear, side, roof or front of the vehicle, providing all round safety and increased visibility.

Designed with flexibility and superior performance in mind, there is a multitude of options to suit, dependent on your intended application.


FEATURES
– Fully compatible with ARB’s reversing camera and monitor system and trailer camera kit (sold separately)
– Quality Sony CCD imager with inbuilt microphone is designed to work effectively in all environments
– Infrared distance of 10 metres for vision at night
– Heavy duty mounting bracket ensures camera can be rotated 120 degrees for optimal view
– Strong, powder coated aluminium housing
– Adjustable visor for glare reduction
– Dustproof and waterproof to IP68 rating
– Heavy duty waterproof cords and connectors
– 6.5 metre cord ensures versatile camera location

Additional information

Image Sensor

1/4" Sony super CCD

Lens

135° wide angle

Pixel Resolution

NTSC 510 x 492 / PAL 500 x 582

Infrared Sensor

Automatic control

Infrared Distance

10m

Illumination

0 Lux (IR on)

Immersion Protection

IP68

Operating Temperature Range

-10°C to 80°C

Operating Voltage

12/24 VDC

Sound (dB)

Better than 48dB

Vibration

5.0 G

Camera Connection

S-Video 4 pin (Male) waterproof connectors

Camera Cable

0.9m with grommet (20mm)

Camera Extension Cable

6.5m S-Video (Male) to S-Video waterproof connector (Female)
